ADAM-5057S

General ƒ Certification CE, FCC class A ƒ Connectors 1 x 40 pin (wiring line) ƒ Enclosure ABS+PC ƒ LED Indicator On: Active Off: Inactive ƒ Power Consumption 1W (Max.) Digital Output ƒ Channels 32 ƒ Digital Output Must connect with 2 units of ADAM-3920R Protection ƒ Optical Isolation 2,500 VDC ƒ Overvoltage 70 VDC Protection Relay Spec. of ADAM-3920R ƒ Contact Rating 10A @ 250 VAC 10A @ 30 VDC ƒ Contact Resistance 100 mΩ ƒ Operation Time 15 ms ƒ Relay Type SPST (Form A) ƒ Release Time 5 ms max ƒ Life Expectancy 1.7 x 105 at related load ƒ Insulation Resistance1GΩ @ 500 VDC ƒ Power Input +24 VDC ƒ Mounting DIN 35 rail, wall, rack (with mounting kit) Note: ADAM-5057S must connect with 2 units of ADAM-3920R via PCL-10220 Note: only for ADAM-5550 & 5560 Series

订货信息：ƒ ADAM-5057S 32-ch Digital Output Module ƒ ADAM-3920R 20-pin Flat Cable Wiring Relay Board ƒ PCL-10220 40-pin IDC to two 20-pin IDC cable, 1m
